6000 Series Purge/Pressurization System
I/O Manual
- TEMP INPUT 2 -
TEMP FUNCTION
(DISABLED)
- DISABLED -
- TEMP FUNCTION -
IMMEDIATE
SHTDN
-
DOOR OPEN
ALARM
- OVERLOAD
-
CTRL PWR
RELAY
-
CTRL
OUTPUT 1
-
CTRL
OUTPUT 2
- CTRL VALVE
- ALARM
- SETPOINT TYPE -
*AVERAGE
SINGLE PT
-
- ON SETPOINT - XX °F (°C) -
- OFF SETPOINT - XX °F (°C) -
-
OUTPUT
SETTINGS
-
OUTPUT 1 FUNCTION
(DISABLED)
- DISABLED
-
IMMED SHUTDN
ALARM
-
DOOR OPEN
ALARM
-
OVERLOAD/TEMP
ALARM
-
MAX PRESSURE
ALARM
-
LOW PRESSURE
ALARM
-
LOST PRESSURE
ALARM
-
ANNOUNCE
PURGE
- ANY ALARM
- ENCL DOOR LOCK
-
SYS BYPASS
ALARM
-
TEMP INPUT 1
ALARM
-
TEMP INPUT 2
ALARM
