A response appears in the input field:
Send a Change tagcommand to channel 3 as an implicit command:
A command confirmation appears in the input field:
A response appears in the input field:
Byte no. Use Contents Description
Byte 0 Command code 04h Command CT (Change tag)
Byte 1 Number of double words/
Channel/Toggle bit
02h Channel = 1
Toggle bit = 0
Byte 2 Status 00h Command executed.
Byte 3 Reply counter 02h For every IDENT telegram, the value
on the reply counter increases by 1.
Byte 4
...
Byte 11
00h
Byte no. Use Contents Description
Byte 0 Command code 04h Command CT (Change tag)
Byte 1 Channel/Toggle bit 06h Channel = 3
Toggle bit = 0
Byte 2 Tag type (high byte) 30h IPC 02
Byte 3 Tag type (low byte) 32h IPC 02
Byte 4
...
Byte 11
00h
Byte no. Use Contents Description
Byte 0 Command code 04h Command CT (Change tag)
Byte 1 Number of double words/
Channel/Toggle bit
06h Channel = 3
Toggle bit = 0
Byte 2 Status FFh Processing command.
Byte 3 Reply counter 03h For every IDENT telegram, the value
on the reply counter increases by 1.
Byte 4
...
Byte 11
00h
Byte no. Use Contents Description
Byte 0 Command code 04h Command CT (Change tag)
Byte 1 Number of double words/
Channel/Toggle bit
06h Channel = 3
Toggle bit = 0
Byte 2 Status 00h Command executed.
Byte 3 Reply counter 04h For every IDENT telegram, the value
on the reply counter increases by 1.
Byte 4
...
Byte 11
00h
Note!
Alternatively select the tag type by configuring the relevant setting in the boot-up object.
