2014-02
108
IC-KP-B17-AIDA1
Appendix A
Reading data carriers on the R/W heads on channels 1 and 3.
Send a Single readcommand to channel 1 as an implicit command:
A command confirmation appears in the input field:
A response appears in the input field:
Byte no. Use Contents Description
Byte 0 Command code 01h Command SF (Single read read
only code)
Byte 1 Channel/Toggle bit 02h Channel = 1
To gg le b it = 0
Byte 2 00h
Byte 3 00h
Byte 4 00h
Byte 5 00h
Byte 6 00h
Byte 7 00h
Byte 8 00h
Byte 9 00h
Byte 10 00h
Byte 11 00h
Byte no. Use Contents Description
Byte 0 Command code 01h Command SF (Single read read
only code)
Byte 1 Channel/Toggle bit 02h Channel = 1
To gg le b it = 0
Byte 2 Status FFh Processing command.
Byte 3 Reply counter 05h For every IDENT telegram, the
value on the reply counter
increases by 1.
Byte 4 00h
Byte 5 00h
Byte 6 00h
Byte 7 00h
Byte 8 00h
Byte 9 00h
Byte 10 00h
Byte 11 00h
Byte no. Use Contents Description
Byte 0 Command code 01h Command SF (Single read read
only code)
Byte 1 Channel/Toggle bit 02h Channel = 1
To gg le b it = 0
Byte 2 Status 00h Command executed.
Byte 3 Reply counter 06h For every IDENT telegram, the
value on the reply counter
increases by 1.
