Send a Single readcommand to channel 3 as an implicit command:
A command confirmation appears in the input field:
Byte 4 ID code 00h ... FFh - <ID code>
Byte 5 ID code 00h ... FFh - <ID code>
Byte 6 ID code 00h ... FFh - <ID code>
Byte 7 ID code 00h ... FFh - <ID code>
Byte 8 ID code 00h ... FFh -
<ID code>
1
Byte 9 00h
Byte 10 00h
Byte 11 00h
1. only IPC02 and IPC11
Byte no. Use Contents Description
Byte 0 Command code 01h Command SF (Single read read
only code)
Byte 1 Channel/Toggle bit 06h Channel = 3
To gg le b it = 0
Byte 2 00h
Byte 3 00h
Byte 4 00h
Byte 5 00h
Byte 6 00h
Byte 7 00h
Byte 8 00h
Byte 9 00h
Byte 10 00h
Byte 11 00h
Byte no. Use Contents Description
Byte 0 Command code 01h Command SF (Single read read
only code)
Byte 1 Channel/Toggle bit 06h Channel = 3
To gg le b it = 0
Byte 2 Status FFh Processing command.
Byte 3 Reply counter 07h For every IDENT telegram, the
value on the reply counter
increases by 1.
Byte 4 00h
Byte 5 00h
Byte 6 00h
Byte 7 00h
Byte 8 00h
Byte 9 00h
Byte 10 00h
Byte 11 00h
Byte no. Use Contents Description
