IC-KP-B17-AIDA1
Commands
2014-02
63
configuration store (CS)
Command:
Response:
The configuration store (CS) command allows you to store the last command sent to the R/W
head in the non-volatile memory of the IDENTControl. The R/W head executes the command
automatically again if the power supply is interrupted or the IDENTControl is reset.
<Mode>='1' activates the mode.
<Mode>='0' deactivates the mode.
Configuration store is deactivated by default.
Byte Contents Bit no.
7 6 5 4 3 2 1 0
Byte 0
1)
Telegram length, high byte 0 0 0 0 0 0 0 0
Byte 1
1)
Telegram length, low byte 0 0 0 0 0 1 0 1
Byte 2 Command code (17h) 0 0 0 1 0 1 1 1
Byte 3 Reserved/Ident channel/Toggle
bit
- - - - <Channel> <T>
Byte 4 Mode 0 0 0 0 0 0 0 <M>
1)
This byte is only used with the TCP/IP and MODBUS TCP/IP protocol.
Byte Contents Bit no.
7 6 5 4 3 2 1 0
Byte 0
1)
Telegram length, high byte 0 0 0 0 0 0 0 0
Byte 1
1)
Telegram length, low byte 0 0 0 0 0 1 0 1
Byte 2 Command code (17h) 0 0 0 1 0 1 1 1
Byte 3 Reserved/Ident channel/Toggle
bit
- - - - <Channel> <T>
Byte 4 Status <Status>
Byte 5 Reply counter <ReplyCounter>
1)
This byte is only used with the TCP/IP and MODBUS TCP/IP protocol.
