Pepperl+Fuchs IC-KP-B17-AIDA1 - Page 64

2014-02
64
IC-KP-B17-AIDA1
Commands
reset (RS)
Command:
This command terminates all active commands. The device settings are reloaded from the
non-volatile memory.
This confirmation is issued for this command (status FFh) instead of a response. The device
resets the hardware and then restarts.
set multiplexed mode (MM)
Command:
Response:
This command switches multiplex mode on and off. In multiplex mode, the R/W heads are
controlled according to the time multiplex process, i.e. only one R/W head is active. The
procedure minimizes mutual interference between R/W heads, allowing two R/W heads to be
mounted side by side.
Byte Contents Bit no.
7 6 5 4 3 2 1 0
Byte 0
1)
Telegram length, high byte 0 0 0 0 0 0 0 0
Byte 1
1)
Telegram length, low byte 0 0 0 0 0 1 0 0
Byte 2 Command code (16h) 0 0 0 1 0 1 1 0
Byte 3 Reserved/Channel/Toggle bit 0 0 0 0 0 0 0 <T>
1)
This byte is only used with the TCP/IP and MODBUS TCP/IP protocol.
Byte Contents Bit no.
7 6 5 4 3 2 1 0
Byte 0
1)
Telegram length, high byte 0 0 0 0 0 0 0 0
Byte 1
1)
Telegram length, low byte 0 0 0 0 0 1 0 1
Byte 2 Command code (9Bh) 1 0 0 1 1 0 1 1
Byte 3 Reserved/Toggle bit 0 0 0 0 0 0 0 <T>
Byte 4 Multiplex mode 0 0 0 0 0 0 0 <F>
1)
This byte is only used with the TCP/IP and MODBUS TCP/IP protocol.
Byte Contents Bit no.
7 6 5 4 3 2 1 0
Byte 0
1)
Telegram length, high byte 0 0 0 0 0 0 0 0
Byte 1
1)
Telegram length, low byte 0 0 0 0 0 1 1 0
Byte 2 Command code (9Bh) 1 0 0 1 1 0 1 1
Byte 3 Reserved/Toggle bit 0 0 0 0 0 0 0 <T>
Byte 4 Statu s <Status>
Byte 5 Reply counter <ReplyCounter>
1)
This byte is only used with the TCP/IP and MODBUS TCP/IP protocol.
