IC-KP-B17-AIDA1
Commands
2014-02
85
<ByteNum> = 0h deletes this filter.
fill tag (S#)
Command:
Response:
The word number <WordNum> of fill signs <Fill Sign> is written to the read/write tag from the
specified start address <WordAddr>.
Extended commands for type IDC-... and IUC… tags
Type IDC-...-1K tags can be programmed to read 24-bit information (so-called special read
only code) very quickly. This is useful for detecting containers in automated warehouses.
Note!
The TI command only adjusts a setting in the reading head. There is no HF communication
with the read/write tags.
Byte Contents Bit no.
7 6 5 4 3 2 1 0
Byte 0
1)
Telegram length, high byte 0 0 0 0 0 0 0 0
Byte 1
1)
Telegram length, low byte 0 0 0 0 1 0 0 1
Byte 2 Command code (AAh) 1 0 1 0 1 0 1 0
Byte 3 Reserved/Ident channel/Toggle
bit
<Reserved> <Channel> <T>
Byte 4 Start address <WordAddr> (high byte)
Byte 5 Start address <WordAddr> (low byte)
Byte 6 Word count <WordNum> (high byte)
Byte 7 Word count <WordNum> (low byte)
Byte 8 Character <Fill Sign>
1)
This byte is only used with the TCP/IP and MODBUS TCP/IP protocol.
Byte Contents Bit no.
7 6 5 4 3 2 1 0
Byte 0
1)
Telegram length, high byte 0 0 0 0 0 0 0 0
Byte 1
1)
Telegram length, low byte 0 0 0 0 0 1 1 0
Byte 2 Command code (AAh) 1 0 1 0 1 0 1 0
Byte 3 Reserved/Ident channel/Toggle
bit
<Reserved> <Channel> <T>
Byte 4 Status <Status>
Byte 5 Reply counter <ReplyCounter>
1)
This byte is only used with the TCP/IP and MODBUS TCP/IP protocol.
Length of the special read only code:
■ Tag of the type IDC-...-1K: 48 bit
■ Tag of the type IUC: 96 ... 240 bit
