IC-KP-B17-AIDA1
Commands
single program special fixcode (SP)
Command:
Response:
The R/W head makes only one attempt to write a special read only code.
Byte Contents Bit no.
7 6 5 4 3 2 1 0
Byte 0
1)
Telegram length, high byte 0 0 0 0 0 0 0 0
Byte 1
1)
Telegram length, low byte 0 0 0 0 1 0 1 0
Byte 2 Command code (0Dh) 0 0 0 0 1 1 0 1
Byte 3 Word number/Iden t
channel/Toggle bit
<FixLen> <Channel> <T>
Byte 4 Reserved 0 0 0 0 0 0 0 0
Byte 5 Reserved 0 0 0 0 0 0 0 0
Byte 6
2)
ID code 00h ... FFh <IDCode>
... ID code 00h ... FFh <IDCode>
Byte N
3)
ID code 00h ... FFh <IDCode>
1)
This byte is only used with the TCP/IP and MODBUS TCP/IP protocol.
2)
The first byte indicates whether an EPC code is shown
■ 1 = EPC application
■ 0 = 18000-6C (ISO)
3)
N = <FixLen> + 5; Ethernet/IP: N = <FixLen> + 3
Byte Contents Bit no.
7 6 5 4 3 2 1 0
Byte 0
1)
Telegram length, high byte 0 0 0 0 0 0 0 0
Byte 1
1)
Telegram length, low byte 0 0 0 0 1 0 1 0
Byte 2 Command code (0Dh) 0 0 0 0 1 1 0 1
Byte 3 FixLen/Ident channel/Toggle bit <FixLen> <Channel> <T>
Byte 4 Statu s <Status>
Byte 5 Reply counter <ReplyCounter>
1)
This byte is only used with the TCP/IP and MODBUS TCP/IP protocol.
