IC-KP-B17-AIDA1
Commands
2014-02
89
enhanced program special fixcode (EP)
Command:
Response:
The R/W head attempts to write a special read only code until successful. After each
successful write, the head sends the response and then switches to continuous reading. Then
the R/W head reads the same data carrier until it has left the detection range or a new data
carrier appears within the detection range. The command then starts again with write attempts.
The status '05h' (read/write command) is output when the data carrier leaves the detection
range or if the data carrier is not yet within the detection range when the command is executed.
If two data carriers enter the read range one immediately after the other, the status '05h' is not
issued between the two readings.
Byte Contents Bit no.
7 6 5 4 3 2 1 0
Byte 0
1)
Telegram length, high byte 0 0 0 0 0 0 0 0
Byte 1
1)
Telegram length, low byte 0 0 0 0 1 0 1 0
Byte 2 Command code (75h) 0 1 1 1 0 1 0 1
Byte 3 FixLen/Ident channel/Toggle bit <FixLen> <Channel> <T>
Byte 4 Reserved 0 0 0 0 0 0 0 0
Byte 5 Reserved 0 0 0 0 0 0 0 0
Byte 6
2)
ID code 00h ... FFh <IDCode>
... ID code 00h ... FFh <IDCode>
Byte N
3)
ID code 00h ... FFh <IDCode>
1)
This byte is only used with the TCP/IP and MODBUS TCP/IP protocol.
2)
The first byte indicates whether an EPC code is shown
■ 1 = EPC application
■ 0 = 18000-6C (ISO)
3)
N = <FixLen> + 5; Ethernet/IP: N = <FixLen> + 3
Byte Contents Bit no.
7 6 5 4 3 2 1 0
Byte 0
1)
Telegram length, high byte 0 0 0 0 0 0 0 0
Byte 1
1)
Telegram length, low byte 0 0 0 0 1 0 1 0
Byte 2 Command code (75h) 0 1 1 1 0 1 0 1
Byte 3 FixLen/Ident channel/Toggle bit <FixLen> <Channel> <T>
Byte 4 Status <Status>
Byte 5 Reply counter <ReplyCounter>
1)
This byte is only used with the TCP/IP and MODBUS TCP/IP protocol.
