Pepperl+Fuchs IC-KP-B17-AIDA1 - Page 90

2014-02
90
IC-KP-B17-AIDA1
Commands
initialize tag (SI)
Command:
Response:
This command allows conventional reading and writing of IDC-...-1K read/write tags that were
configured using the EP or SP commands.
Byte Contents Bit no.
7 6 5 4 3 2 1 0
Byte 0
1)
Telegram length, high byte 0 0 0 0 0 0 0 0
Byte 1
1)
Telegram length, low byte 0 0 0 0 0 1 0 0
Byte 2 Command code (6Bh) 0 1 1 0 1 0 1 1
Byte 3 Reserved/Channel/Toggle bit 0 0 0 0 <Channel> <T>
1)
This byte is only used with the TCP/IP and MODBUS TCP/IP protocol.
Byte Contents Bit no.
7 6 5 4 3 2 1 0
Byte 0
1)
Telegram length, high byte 0 0 0 0 0 0 0 0
Byte 1
1)
Telegram length, low byte 0 0 0 0 1 0 1 1
Byte 2 Command code (6Bh) 0 1 1 0 1 0 1 1
Byte 3 Reserved/Channel/Toggle bit 0 0 0 0 <Channel> <T>
Byte 4 Statu s <Status>
Byte 5 Reply counter <ReplyCounter>
1)
This byte is only used with the TCP/IP and MODBUS TCP/IP protocol.
