Commands
write param (WP)
Command:
Response:
Byte Contents Bit no.
7 6 5 4 3 2 1 0
Byte 0
1)
Telegram length, high byte 0 0 0 0 0 0 0 0
Byte 1
1)
Telegram length, low byte 0 0 0 0 0 1 0 0
Byte 2 Command code (BFh) 1 0 1 1 1 1 1 1
Byte 3 Reserved/Ident channel/Toggle bit - <Channel> <T>
Byte 4 Reserved 0
Byte 5 System code <SystemCode>
Byte 6 Parameter type <ParamTyp> (high byte)
Byte 7 Parameter type <ParamTyp> (low byte)
Byte 8 Length 00 … FFh <DataLength> (high byte)
Byte 9 Length 00 … FFh <DataLength> (low byte)
Byte 10 Data 00 ... FFh <Data>
... Data 00 ... FFh <Data>
Byte N
2)
Data 00 ... FFh <Data>
1)
This byte is only used with the TCP/IP and MODBUS TCP/IP protocol.
2)
N = <DataLength> + 6
Byte Contents Bit no.
7 6 5 4 3 2 1 0
Byte 0
1)
Telegram length, high byte 0 0 0 0 0 0 0 0
Byte 1
1)
Telegram length, low byte 0 0 0 0 1 0 1 1
Byte 2 Command code (BFh) 1 0 1 1 1 1 1 1
Byte 3 Reserved/Ident channel/Toggle bit 0 <Channel> <T>
Byte 4 Statu s <Status>
Byte 5 Reply counter <ReplyCounter>
1)
This byte is only used with the TCP/IP and MODBUS TCP/IP protocol.
IQH2-...: <SystemCode> = 'Q' ASCII (51
h
)
<ParamTyp> = 'K1' ASCII (4B
h
31
h
)
RP: reads the key (12 characters ASCII from 0 ... F) from the
transponder and the read head
WP: writes the key (12 characters ASCII from 0 ... F) into the
read head
Default key = 'FF FF FF FF FF FF' ASCII
(46
h
46
h
46
h
46
h
46
h
46
h
46
h
46
h
46
h
46
h
46
h
46
h
)
IUH-...: See handbook of the read / write head
