2023-05
28
VisuNet Control Center 6
Manage (Home)
Figure 6.15
When every device Status is set to "Success", the performed action is completed and the
wizard can be finished
Broadcast Message
1. With one or more RMs selected, click the "Broadcast Message" icon.
Figure 6.16 Broadcast Message Window
2. Type a message into the space provided. Click "OK".
Figure 6.17 Fly-in message on RM Screen
The text that you entered appears in a fly-in message to the users of the selected RMs.
