Lumina XRMS Series III Hardware Manual Chapter 7 | Basic Operation 47
"GAS IN" means the direction of flow is into that port. Similarly, the port labeled "GAS OUT" means
that flow can be exhausted out of this port.
Figure 7.3 External Gas Ports on Rear of Instrument
WARNING! Use only isoflurane with the IVIS Lumina XRMS Series III. DO NOT USE
FLAMMABLE ANESTHESIA GAS.
CAUTION: It is recommended to use the XGI-8 Gas Anesthesia System when
imaging small animals (Figure 7.4). The system supplies a controlled amount of
isoflurane to the imaging chamber and continuously reduces the build-up of
isoflurane in the chamber. If you want to use a gas other than the recommended
isoflurane/oxygen gas mixture or pure air, contact PerkinElmer Technical Support
(see page 24).
Figure 7.4 XGI-8 Gas Anesthesia Delivery System
