Lumina XRMS Series III Hardware Manual Chapter 9 | Care and Maintenance 71
2. Using the Living Image software service software commands, move the scintillation plate to the
center of the stage (Figure 9.2).
3. Wet a small portion of the soft, lint-free wipe (PerkinElmer part no. 126291) with the optical
cleaner (PerkinElmer part no. 123495) (Figure 9.3).
Figure 9.1 Gas Manifold Connections
Figure 9.2 Scintillation Plate Moved to Center of the Stage
Gas tubing connected
at the right-hand elbow
on the gas manifold
Gas tubing connected
at the barbed fitting
on the stage
Gas manifold gas hose disconnected from the
right-hand elbow
