Explorer Mini Repairs - Circuit breakers
Figure 109. Remove the cover from the main circuit
breaker.
3. Remove the two screws from the cover of the main circuit breaker.
Figure 110. Remove the main circuit breaker.
4. Press the snap-fit joint with a screwdriver or pliers, one side at a
time, to remove the main circuit breaker from the bottom cover.
58
