Permobil Explorer Mini - Removing the Start Button

Explorer Mini Repairs - Circuit breakers
4.11.4 Removing the start button
• Torque wrench.
• Torx T8 socket.
• Pliers.
1. Remove the top cover. For instructions, see
4.6.1.1
Removing the top cover .
Figure 115. Disconnect the cable to the start button
from the battery saving module.
2. Disconnect the cable to the start button from the battery saving
module.
Figure 116. Remove the start button.
3. Press the snap-fit joint with a screwdriver or pliers, one side at a
time, to remove the start button from the bottom cover.
61
