Permobil Explorer Mini - Page 64

Explorer Mini
Repairs - Drive unit
Figure 122. Pull off the wheel hub from the axle.
7. Pull off the wheel hub from the axle to each drive unit.
Figure 123. Remove the drive unit.
8. Remove the three screws from each drive unit and remove the
drive units.
64
