Specifi cations
10
3 Specifi cations
▲
Rated values
Voltage: ........................................................................................................230 V, single-phase
Frequency: ....................................................................................................................50/60Hz
Current for drive ED QE3760 / EDL QE5540:......................................................... 3,5 A / 5,0 A
Current for control unit: ......................................................................................................0,6 A
Power output ED QE3760 / EDL QE5540: ......................................................... 375 W / 550 W
Speed: ED QE3760 / EDL QE5540: .......................................................6000 min
-1
/ 4000 min
-1
Torque: ED QE3760 / EDL QE5540: .............................................................. 0,63 Nm / 1,2 Nm
Moment of inertia of motor (without belt pulley):
ED QE3760 / EDL QE5540:..................................................................... 0,5 kgcm² / 1,0 kgcm²
Operating mode: ...........................................................S5 (40% rel. on-time for 2.5 s runtime)
Protection system: .............................................................................................................IP40
Insulation class: ......................................................................................................................E
Limit values
Rated voltage range: ..........................................................................180 - 260 V, single-phase
Max. motor speed: ED QE3760 / EDL QE5540: ................................... 9000 min
-1
/ 4500 min
-1
Max. torque (short time): ED QE3760 / EDL QE5540: .......................................... 3 Nm / 7 Nm
Max. power output (short-time): ED QE3760 / EDL QE5540: ........................1000 W / 1500 W
Moment of inertia of machine (reduced to motor shaft):
ED QE3760 / EDL QE5540:..................................................................... 4,5 kgcm² / 9,0 kgcm²
Operating requirements
Ambient temperature: .......................................................................................... +5 to +45° C
Average ambient temperature (over 24 hours): .............................................................<35° C
Relative humidity: ................................................................................................85% at 30° C
Control voltage for external control elements
Voltage with engine idling: .................................................................................................. 25 V
Voltage under load: ......................................................24 V bei 4 A / 20 V bei 10 A (short-time)
Output: ..............................................................................................96 W / 200 W (short-time)
Load current: .........................................................................................................................4 A
Max. load current (short-time):............................................................................................ 10 A
The sum of the load currents of all simultaneously activated control elements
must not continuously exceed 4 A .
Weights
Net weight (drive complete with all accessories): .................................................approx. 9 kg
Gross weight: ....................................................................................................... approx. 11 kg
▲
Subject to alteration
