9.01.03 List of parameters for control unit P40 ED
Only appropriately trained personnel is authorized to alter the set values in the
parameters of user level "B" and "C".
With this control unit following machine types are programmable:
Machine type 1 = series 480, 910, 930, 1180 (without -712/..), 3704 and 5480
Machine type 2 = series 570, 590, 330 (except 333,) 1240, 1290
Machine type 3 = 1163
Machine type 4 = 333-712/..
Machine type 5 = 1183-712/..
Group
Parameter
Description
Machine type
User level
Setting range
Set value
1
101 Acoustic signal of control panel keys 1, 2, 3, 4, 5 A ON - OFF OFF
105 Speed at seam start 1
2
3, 4, 5
B
B
B
100 - 2000
100 - 2000
100 - 2000
1600
700
1200
106 Speed at seam start
ON = variable (pedal-controlled)
OFF = constant (as for parameter 105)
1, 2, 3, 4, 5 B ON - OFF OFF
107 Speed at seam start
ON = limited by parameter 105
OFF = limited by parameter 607
1, 2, 3, 4, 5 B ON - OFF OFF
110 Speed at seam end 1
2
3, 4, 5
B
B
100 - 2000
100 - 2000
100 - 2000
1600
700
1200
111 Light barrier compensating stitches 1, 2, 3, 4, 5 A 1 - 30 8
112 No. of stitches for blocking out light
barrier for knitted fabrics
1, 2, 3, 4, 5 A 0 - 100 0
113 Start with light barrier
ON = only if light barrier dark
OFF = also when light barrier bright
1, 2, 3, 4, 5 B ON - OFF OFF
116 Soft starting stitches (soft start) 1
2, 3, 4, 5
A
A
0 - 30
0 - 30
1
0
117 Speed for soft starting stitches (soft
start)
1
2, 3, 4, 5
B
B
30 - 4000
30 - 4000
1000
400
163 Sewing with light barrier 1, 2, 3, 4, 5 B ON - OFF OFF
