Input P70 ED
46
9.01.05 List of parameters for control unit P70 ED
Only appropriately trained personnel is authorized to alter the set values in the
parameters of user level "B" and "C".
Group
Parameter
Description
Machine type
User level
Setting range
Set value
1
101 Acoustic signal of control panel keys 1, 2, 3 A ON - OFF OFF
105 Speed at seam start 1, 2
3
B
B
100 - 6400
100 - 6400
1200
1000
106 Speed at seam start
ON = variable (pedal-controlled)
(as for parameter 107)
OFF = constant (as for parameter 105)
1, 2, 3 B ON - OFF OFF
107 Speed at seam start
ON = limited by parameter 105
OFF = limited by parameter 607
1, 2, 3 B ON - OFF OFF
110 Speed at seam end 1, 2
3
B
B
100 - 6400
100 - 6400
1200
1000
111 Light barrier compensating stitches 1, 2, 3 A 1 - 255 8
112 No. of stitches for blocking out light
barrier for knitted fabrics
1, 2, 3 A 0 - 255 0
113 Start with light barrier
ON = only if light barrier dark
OFF = also when light barrier bright
1, 2, 3 B ON - OFF OFF
116 Soft starting stitches (soft start) 1, 2, 3 A 0 - 255 0
117 Speed for soft starting stitches (soft
start)
1, 2, 3 B 30 - 640 400
118 Output A 37 is:
ON = needle cooling
OFF = motor operation
1, 2, 3 B ON - OFF ON
147 Move to bearing position
ON = in reverse
OFF = forwards
1, 2
3
-
B
-
ON - OFF
-
ON
