Sewing
20
8.01.03 Set bobbin thread control by stitch counting
Switch on the machine. ●
Press the "TE/Speed" key twice to call up the parameter input function (LED on). ●
Press the relevant plus-minus keys to select parameter ● 760.
2x
Set the number of remaining stitches, which can still be sewn after recognition through ●
the bobbin thread monitoring function, by pressing the relevant plus-minus key. The
selected value is multiplied by 200, in this way showing the number of stitches.
Example:
Display ● 5(x 200) = 1000 stitches. The setting depends, among other things, on the thread
size.
Press the "TE/speed" key to take over the value and change to the manual sewing mode. ●
The remaining bobbin thread counter can only be used, if parameter 660 is set
at value "1" or "2".
8.01.04 Bobbin thread monitoring on sub-class -926/06 (optional)
Setting the bobbin thread monitor function, see Instruction Manual -926/06
(part no. 296-12-18 770/001).
No VAL
A 101 ON
No VAL
A 760 5
