# Display Designations Functions Data
type
Access
type
Unit min. max. de-
fault
794 Param set Parameter set 0 = Basic pa-
rameter set
1 = Extended
parameter set
7 RW 0 1 0
795 Servicelin Insert service line 7 RW 795
Tbl. 10: Parameter for DCU functions
5.3 Data types used
Data type Description Length l1 – l0 Example
0 – boolean_old logical value (false/true) 06 000000 corresponds with false
111111 corresponds with true
1 – u_integer pos. whole number 06 000000 to 999999
2 – u_real pos. fixed-point number 06 001571 corresponds with 15.71
4 – string Character string 06 TC_400, TM_700
6 – boolean_new logical value (false/true) 01 0 corresponds with false
1 corresponds with true
7 – u_short_int pos. whole number 03 000 to 999
10 – u_expo_new pos. exponential value 06
100023 corresponds with 1.0 · 10
3
11 – string Character string 16 this-is-an-example
Parameter set
24/38
