1.3.2 Pictographs
Pictographs used in the document indicate useful information.
Note
Tip
1.3.3 Stickers on the product
This section describes all the stickers on the product along with their meaning.
Mod.:
Mod--Nr.:
DCU 110
PM C01 820
Ser. Nr.:
90-265 V 2.0-0,8A 50/60 Hz 125 VA
90 V / 4.6 A 110 W
Made in Germany 2018/06
Input:
Output:
Mass: 1.2 kg
Rating plate (example)
Rating plates of the devices are affixed to the housing where they
can be clearly seen
C
US
Safety approved
USA CAN
TÜV Rheinland
Test seal:
The test seal provides information regarding additional certifica-
tions
Tbl. 1: Stickers on the product
Fig. 1: Position of the labels on the product
1 CAN/USA test seal 3 Rating plate for DCU
2 Rating plate for DCU with power supply pack 4 CAN/USA test seal
1.3.4 Abbreviations
Abbreviation Meaning in this document
AC AC Voltage
APR Piezo transmitter
CMR Capacitive transmitter CMR
DC Direct voltage, operating voltage
DCU Display Control Unit
f Rotation speed value of a vacuum pump (frequency, in rpm or Hz)
LC Liquid crystal
LED Illuminating diode
About this manual
8/38
