Pfeiffer Vacuum DCU 310 - Fig. 11: Dimensions DCU 002; Fig. 12: Dimensions DCU 110; Fig. 13: Dimensions DCU 180, DCU 310, DCU 400

52.5
64.5
11.75
105
106.4
91.5
128.5
122.5
Fig. 11: Dimensions DCU 002
106.5
91.5
128.5 122.5
200
2.5
29.5 29.7
20.
2
59.8
29.4
79.4
109.4
29.7
75.35
104.8
0.5
Fig. 12: Dimensions DCU 110
106.5
91.5
128.5 122.5
230
2.5
29.5 29.7
20.
2
59.8
29.4
79.4
109.4
29.7
75.35
104.8
0.5
Fig. 13: Dimensions DCU 180, DCU 310, DCU 400
Technical data and dimensions
