8 Malfunctions
8.1 General
Vacuum pump and electronic drive unit malfunctions always result in a warning or error message. In
both cases, the LC-display on the DCU shows an error code. LED on the electronic drive unit and on
the DCU illuminate for the corresponding status.
No LC-display
●
Absence of the LC-display is possibly an indication that attachment of the con-
nection cable is faulty:
─
"DCout"
─
"RS485"
─
"X3"
─
"ACin"
8.2 Error codes
In addition to the device-specific waning and error messages for an electronic drive unit, the DCU also
features its own messages. Errors (** Error E–––– **) always cause the connected peripheral devices to
be switched off. Warnings (* Warning F –––– *) do not cause components to be switched off.
Handling of fault messages
1.
Read out the error codes via the display and control panel or the PC.
2.
Remove the cause of the fault.
3.
Reset the error message with parameter [P:009] or by pressing the button on the DCU.
Display in DCU Problem Possible causes Remedy
* Warning F110 * Pressure gauge
●
Pressure gauge faulty
●
Connection to the pressure gauge
disconnected during operation
●
Check the cable connection
●
Carry out a restart with pressure
gauge connected
●
Replace the pressure gauge com-
pletely
** Error E040 ** Hardware error
●
external RAM faulty
●
Contact Pfeiffer Vacuum Service.
** Error E042 ** Hardware error
●
EPROM checksum incorrect
●
Contact Pfeiffer Vacuum Service.
** Error E043 ** Hardware error
●
2
EPROM write error
●
Contact Pfeiffer Vacuum Service.
** Error E090 ** Internal device
error
●
RAM not large enough
●
DCU is connected to incorrect
electronic drive unit
●
Contact Pfeiffer Vacuum Service.
●
Connect the DCU to the correct
electronic drive unit
** Error E698 ** Communication
error
●
Electronic drive unit is not re-
sponding
●
Contact Pfeiffer Vacuum Service.
Tbl. 17: Warning and error messages when using the DCU
Malfunctions
30/38
