11 Technical data and dimensions
11.1 Technical data
Selection field DCU 002, Display Control Unit
Order number PM 061 348 -T
Connection 12 – 30 V DC
Power consumption 5 VA
Protection category IP20
Ambient temperature 5 – 50 °C
Weight 0.4 kg
Tbl. 18: DCU 002
Selection field DCU 110, Display control
unit incl. power supply
DCU 180, Display control
unit incl. power supply
Order number PM C01 820 PM C01 821
Mains requirement: voltage (range) 115–230 (-20-+15 %) V AC 115–230 (-20-+15 %) V AC
Mains requirement: frequency (range) 50/60 Hz 50/60 Hz
Mains requirement: power consump-
tion
130 VA 210 VA
Output current 4.6 A 7.5 A
Output voltage 24 (± 2 %) V DC 24 (± 2 %) V DC
Protection category IP20 IP20
Ambient temperature 5 – 50 °C 5 – 50 °C
Weight 1.2 kg 1.7 kg
Tbl. 19: DCU 110, DCU 180
Selection field DCU 310, Display control
unit incl. power supply
DCU 400, Display control
unit incl. power supply
Order number PM C01 822 PM C01 823
Mains requirement: voltage (range) 115–230 (-20-+15 %) V AC 115–230 (-20-+15 %) V AC
Mains requirement: frequency (range) 50/60 Hz 50/60 Hz
Mains requirement: power consump-
tion
340 VA 450 VA
Output current 12.5 A 8.4 A
Output voltage 24 (± 2 %) V DC 48 (± 2 %) V DC
Protection category IP20 IP20
Ambient temperature 5 – 50 °C 5 – 50 °C
Weight 1.85 kg 2.3 kg
Tbl. 20: DCU 310, DCU 400
11.2 Dimension drawings
All dimensions in mm
Technical data and dimensions
34/38
