Philips 4000 - Milk Carafe

PHILIPS 4000 and 3000 04 OPERATING LOGIC
2/10
 4.2.MilkCarafe4000OTC
1) Steam input
2)Bring the cappuccino maker into dispensing
position
3) Milk tank
1
2
3
The steam passes
through the pipe creating
asuckingeffectthatpulls
themilkupwards
Steam
Themilkisheatedbythe
steamandtakentowards
the emulsion chamber
where it is mixed with
air and transformed into
foam
