Philips 4000 - Coffee Grinder Disassembly

PHILIPS 4000 and 3000 07 DISASSEMBLY
2/9
Upper cover
3000
4000
exploded view of the
coffee dispenser
9
Unscrewthescrewsshown,raisethetopcoverandremovetheelectricalandwatercircuitcon-
nections.
7.2. Coffee grinder
Raise the coffee grinder and remove the connections.
When reassembling the coffee
grinder,makesurethespringis
repositioned correctly (see photo).
The new machines have a coffee grinder with the screw to
prevent the disassembly of the upper coffee grinder support
(see photo).
