104 EN104 EN
VCR FUNCTIONS
Playback Recording
Press [VCR] first.
1) Insert a prerecorded tape (refer to page 25 on how
to insert a cassette tape).
2) Press [PLAY B] to start playback.
3) Press [STOP C] to stop playback.
Note
• When a cassette tape without erase-protection tab is
inserted, the unit will start playback automatically.
• Tracking will be automatically adjusted upon
playback. To adjust the tracking manually, press [CH
/ ] on the remote control.
• S-VHS cassette tape is not available on this unit.
Press [VCR] first.
1) Insert a recordable tape with an erase-protection
tab intact.
Accidental erasure prevention
To prevent accidental recording on a
recorded cassette tape, remove its erase-
protection tab. To record on it later, cover
the hole with cellophane tape.
erase-protection tab
2) Select the recording mode using [REC MODE].
• The desired recording mode is selected in SP
(standard play) or SLP (super long play) mode by
pressing [REC MODE].
Recording mode:
Tape speed Recording / playback time
Type of tape T60 T120 T160
SP mode 1hour 2hours 2-2/3hours
SLP mode 3hours 6hours 8hours
3) Select stereo or SAP. Refer to page 34.
4) Select the desired channel to record using
[CH
/ ] or [the Number buttons].
5) Press [REC I] to start recording.
Press [STOP C] to stop the recording.
To pause recording:
Press [PAUSE F].
To resume recording:
Press [PAUSE F] or [REC I].
After the unit has been in pause mode for 5 minutes, it
will stop automatically to protect the tape and the
video head from damage.
• Refer to pages 42-45 for instructions on timer recording.
To pause playback:
Press [PAUSE F].
Playback will pause and sound will be muted.
To resume playback:
Press [PLAY B].
