ErgoLine D330/D340
Customer Engineer Manual
Page 2-7
D330 Terminal Endpoint Identification (TEI)
In the specification of the terminal message protocol (TMP) a B channel is
identified by a port number. The ErgoLine terminal uses fixed TEIs for B channel
allocation.
For ErgoLine D330 terminals the TEI can have two different values:
0 = B channel 0
1 = B channel 1
When 0 or 1 is selected only one B channel is used for voice. The TEI setting should
only be changed during installation. This is done as follows:
1. Press the
Options
key then scroll down until the
Features
option is displayed
and press the
OK
key.
The following display will appear on the screen:
⋅
2. Scroll down until the
SetPhone
option is displayed and press the
OK
key.
The following display will appear on the screen:
3. Scroll down until the
Select mode
option is displayed and press the
OK
key.
The following display will appear on the screen:
4. Enter the service password of the set,
12687
.
Note
: This password cannot be changed. It is for the use of maintenance
personnel only
The following display will appear on the screen:
5. Press the
OK
key. The display will return to idle indicating that the Service Mode
is active.
[↕ Scroll, OK accept]
Togglelist? ↕
Set language? ↕
[Enter Password]
[↕ Scroll, OK accept]
[Press OK to accept]
*****
