ErgoLine D330/D340
Customer Engineer Manual
Page 2-9
When the ErgoLine terminal has been successfully connected to the following:
•
mains supply where necessary
•
PNT1 or wall socket
The following display will appear on the screen:
The ErgoLine terminal is now ready to receive commands from the Switch.
Programming the ErgoLine terminal is possible before download, however call set-
up is not possible during this time. The default values can be overruled by the
Switch or can be changed by the programming procedure from the ErgoLine
terminal.
When the message
Non-Operational
is removed, which can take a few
moments, dial tone will be received upon lifting the handset.
The following display will appear on the screen:
Note:
If no dial tone is received, check the status of the circuit in the Switch.
D340 Terminal Endpoint Identification (TEI)
In the specification of the terminal message protocol (TMP) a B channel is
identified by a port number. The ErgoLine terminal uses fixed TEIs for B channel
allocation.
For ErgoLine D340 terminals the TEI can have three different values:
•
0 = B channel 0
•
1 = B channel 1
•
0 & 1 = both B channels are used: 0 for voice and 1 for data (only on terminals
with the V.24 option plus external power supply fitted)
When 0 or 1 is selected only one B channel is used for voice: this means that the
V.24 data port remains non-operational and can not be used for data transfer.
The TEI setting should only be changed during installation. This is done as follows:
1. Press the
Features
and
SetPhone
(soft) keys.
Non-Operational
To Next Page
