ErgoLine D330/D340
Customer Engineer Manual
Page 2-29
Optional Interfaces
Audio Interface
The ErgoLine D340 has an optional Audio interface which can be used to
connect audio accessories such as a voice recorder.
The Audio interface is connected via an RJ11 socket on the underside of the
terminal.
This interface complies with the audio section of the X/Y interface specification
AEI Draft I-ETS 300245.
T
ABLE
2-4. A
UDIO
I
NTERFACE
P
IN
C
ONFIGURATION
SIGNAL PIN DESCRIPTION
X_OUT 1 Analogue Output
X_IN 2 Analogue Input
GNDA 3 Ground Analogue
N/C 4
N/C 5
N/C 6
Static Interface
The ErgoLine D340 has an optional Static interface which supplies an output
control line for accessories such as an second bell or a door lamp. It also supplies
a single input channel for foot switch operation.
The Static interface is connected via an RJ11 socket on the underside of the
terminal.
This interface complies with the Y-section of the X/Y interface specification AEI
Draft I-ETS 300245.
