ErgoLine D330/D340
Customer Engineer Manual
Page 2-14
T
ABLE
2-2. F
UNCTION
C
ODES FOR
F
UNCTION
K
EY
D
OWNLOADING
FUNCTION
CODE
FUNCTION TO BE
DOWNLOADED
NUMBER TO BE
STORED ON FIRST
LEVEL
NUMBER TO BE STORED
ON SECOND LEVEL
FACILITY
NUMBER
(optional)
110 Activate auto answer
1hr
None Speed dial number* 38
111 Footpedal None Speed dial number* -
112 Second ringer None Speed dial number* -
113 Busy indication None Speed dial number* -
114 Manual busy
indication
None Speed dial number* -
115 Door opener None Speed dial number* -
116 X-input instead of
microphone
None Speed dial number* -
117 Handset operation
without hook
None Speed dial number* -
118 Headset None Speed dial number* -
Note 1 : See V24 Data Guide for settings
Function Key Layout
When preparing download information in the Switch, it is necessary to know the
numbering of the keys on the ErgoLine. The following diagram shows the
numbering of the keys on the main terminal, the three optional DSS’s and on the
ASCII keypad.
Note
: The format used to describe the numbering is as follows:
(Keypad keys are shifted level only)
Key
= Marking on the terminal (numbers in italics are keypad
key numbers)
Test
= Indication on LCD during the keyboard test in the
maintenance menu
SOPHO
= Function key numbering for downloading from SOPHO iS
in function key menus.
F
IGURE
2-2. E
RGO
L
INE
M
AIN
T
ERMINAL
K
EY
N
UMBERING
