ErgoLine D330/D340
Customer Engineer Manual
Page 2-15
Key 1
Test 1/19
SOPHO 0
Key 7
Test 1/23
SOPHO 6
Key 2
Test 1/13
SOPHO 1
Key
1
Test 1/32
SOPHO 27
Key
2
Test 1/33
SOPHO 28
Key
3
Test 1/34
SOPHO 29
Key 8
Test 1/17
SOPHO 7
Key 3
Test 1/31
SOPHO 2
Key
4
Test 1/26
SOPHO 30
Key
5
Test 1/27
SOPHO 31
Key
6
Test 1/28
SOPHO 32
Key 9
Test 1/35
SOPHO 8
Key 4
Test 1/25
SOPHO 3
Key
7
Test 1/44
SOPHO 33
Key
8
Test 1/45
SOPHO 34
Key
9
Test 1/46
SOPHO 35
Key 10
Test 1/29
SOPHO 9
Key 5
Test 1/43
SOPHO 4
Key ✳
Test 1/38
SOPHO 36
Key
0
Test 1/39
SOPHO 26
Key
#
Test 1/40
SOPHO 37
Key 11
Test 1/47
SOPHO 10
Key 6
Test 1/37
SOPHO 5
Key 12
Test 1/41
SOPHO 11
Figure 2-3. ErgoLine Terminal Key Numbering : other keys
KEY DESCRIPTION TEST INDICATION
Volume - 1/0
Volume + 1/1
Softkey 1 1/2
Softkey 2 1/3
Softkey 3 1/4
Softkey 4 CANCEL (exits from test)
Loudspeaker 1/18
Last Number Redial 1/6
Mute 1/7
Exit 1/8 (also exits from test)
Cursor up 1/9
Cursor down 1/15
Cursor left 1/14
Cursor right 1/21
Backspace 1/22
Help 1/16
Shift 1/10
Hold 1/11
Hookswitch 1/48
