ErgoLine D330/D340
Customer Engineer Manual
Page 2-34
•
Display Calling Number
Data Transfer Parameters
The
baud rate
can be set up to the rates specified in the following table. This
transfer mode and rate adaptation are fixed for each baud rate. The rate must
match the baud rate of the attached V.24 device.
T
ABLE
2-8. D
ATA
T
RANSFER
P
ARAMETERS
BAUD
RATE
TRANSFER
MODE
RATE
ADAPTATION
300 Asynchronous V.110
600 Asynchronous V.110
1200 Asynchronous V.110
1800 Asynchronous V.110
2400 Asynchronous V.110
4800 Asynchronous V.110
9600 Asynchronous V.110
19200 Asynchronous V.110
38400 Asynchronous V.110
48000 Synchronous X.30
54000 Synchronous X.30
64000 Synchronous X.30
The
data word length
can be set to 7 or 8 bits. Odd, even or no parity can be
specified and the number of stop bits can be 1 or 2. The following table lists these
options. The settings must match the settings of the V.24 device to which the
ErgoLine D340 is connected.
T
ABLE
2-9. D
ATA
B
YTE
S
IZE
CHAR.
LENGTH
PARITY STOP BITS
8 bits none 1
8 bits even 1
8 bits odd 1
8 bits none 2
8 bits even 2
8 bits odd 2
7 bits none 1
7 bits even 1
7 bits odd 1
7 bits none 2
7 bits even 2
7 bits odd 2
