Philips Pathology Scanner SG20 - Glass Slide Racks; Digital Slide Image

Glass slide racks Technical data
103
4522 207 12671 * 2021-06-17
Pathology Scanner SG20 / SG60 / SG300
Definition Specification
Slide label on top of a cover slip
Cover slip on top of a slide label
At least 18 mm x 18 mm of the cover slip is not covered by or not on
top of a label.
Orientation Max ± 5 degrees relative to glass slide edge
Tab. 42: Slide label specification
Glass slide racks
Definition Specification
Type Winlab LS-20
Winlab LSM-20
Sakura 4768 20-Slide Basket
Max. number of slides 20
Tab. 43: Glass slide racks
NOTICE
Only use clean glass slide racks.
Prevent accumulation of dust and wax particles inside the scanner as this can interfere with
the scanning process.
Digital slide image
Images of the scanner meet the following specifications:
Parameter Specification
Pixel size (40x image) 0.25 μm
Tab. 44: Pixel size
Parameter Specification
Image compression level The scanner supports 1 level of compression:
Level 2 = 15 x compression
Output format iSyntax, Philips proprietary format
(for all image compression levels & RAW).
Tab. 45: Image format
Parameter Specification
Data format label image JPEG
Tab. 46: Label image
