Technical data Supported tissue samples
98
4522 207 12671/ * 2021-06-17
Pathology Scanner SG20 / SG60 / SG300
Definition Specification
Average percentage of tissue that is detected and scan-
ned.
≥ 99.5%
Tab. 36: Tissue coverage
WARNING
Due to the characteristics of the scanner, some tissue on the glass slide might not be shown
in the macro image and can be located outside the indicated scan regions.
Take appropriate actions, when you think the shown tissue might be incomplete.
Supported tissue samples
Definition Specification
Tissue stains Bright field stains for slides prepared from formalin-fixed paraffin
embedded (FFPE) tissue
Tissue size At least 0.4 x 0.4 mm
Tissue thickness 3-5 μm
Tab. 37: Supported tissue samples
See chapter “Preparation of slides” on page 27 for recommendations on slide preparation.
Glass slides, cover slips and markers
Glass slides, cover slips and markers that meet the following specifications are supported:
Definition Specification
Dimensions
Length 75 – 76 mm
Width 25 – 26 mm
Thickness 0.9 – 1.2 mm
Flatness deviation ≤ 50 µm
Sides
