Axioline F local bus There is an interface to the Axioline F local bus on the bottom of the controller. Bus base
modules are used to carry the communications voltage and the bus signals from the con-
troller through the Axioline F station. A bus base module is supplied with the controllers.
Up to 63 Axioline F modules can be connected to the controllers. The modules are con-
nected to the right of the controller. The maximum number of modules that can be operated
depends on the current consumption of the modules. The total current consumption of all
devices connected to the controller must not exceed the maximum current that the control-
ler supplies for the local bus.
Left-alignment of
Axioline F extension
modules
In principle, you can extend the controllers by connecting Axioline F modules on the right.
Furthermore, you can also add hardware functions to the left of the controller AXC F 2152
and AXC F 3152 devices.
The following left-alignable modules (extension modules) are currently available:
Note the following special characteristics:
For additional information on how to integrate your controller as a PROFINET controller
or device, please refer to the PLCnext Engineer online help.
NOTE: Electronics may be damaged when overloaded
Observe the current consumption of each device when configuring an Axioline F station.
The current consumption is specified in each module-specific data sheet and may vary.
The possible number of devices that can be connected depends on the structure of the
Axioline F station.
Available at the time this user manual was created:
– 2403115 AXC F XT ETH 1TX Left-alignable Ethernet interface
– 2403018 AXC F XT IB Left-alignable INTERBUS master
– 1139999 AXC F XT EXP Left-alignable PCIe extension interface
– 1091657 AXC F XT PB Left-alignable PROFIBUS master
– 1159811 AXC F XT SPLC 1000 Left-alignable safety-related Axioline F controller of performance class 1000
– 1259849 AXC F XT ML 1000 Left-alignable module with machine learning function
In preparation:
– 1160157 AXC F XT SPLC 3000 Left-alignable safety-related Axioline F controller of performance class 3000
Table 3-1 Special characteristics of the left-alignable extension modules in combination with PLCnext Control
devices
Characteristic AXC F 2152 AXC F 3152
Bus base module
– Connection of an
AXC F XT ... to the con-
troller
Replace the bus base module of the con-
troller with the bus base module
AXC BS L 2, Order No. 1064312.
Remove the cap on the left-hand side on the
PLCnext Control bus base module.
– Connection of an
AXC F XT ... to an
AXC F XT ...
To align an additional AXC F XT ... module to the left on an AXC F XT ..., remove the cap
on the bus base module of the preceding module.
