AXC F X152
84 / 104
PHOENIX CONTACT 107708_en_09
Module classification PLCnext Control for direct control of Axioline F I/Os.
Application type Distributed control technology
Operating system Yocto/Linux
Processor Arm
®
Cortex
®
-A9 2x 800 MHz
RAM 512 Mbyte DDR3 SDRAM
Flash memory 512 Mbyte (internal flash memory)
SD card from PhoenixContact (for external flash memory, see
accessories)
Application interface OPCUA
Realtime clock Yes
Controller redundancy yes (applicative system redundancy possible)
External memory yes
Web server yes
Diagnostics display No
Safety function No
Optical interface No
General data
Ambient conditions
Ambient temperature (operation) -25 °C ... 60 °C up to 2000m above mean sea level (observe
derating)
-25 °C ... 55 °C up to 3000m above mean sea level (observe
derating)
≤ 55 °C (with max. 1A on U
Bus
)
> 55 °C ... 60 °C (only in conjunction with an Axioline F power
module AXL F PWR 1H (Item no. 2688297))
Ambient temperature (storage/transport) -40 °C ... 85 °C
Permissible humidity (operation) 5 % ... 95 % (according to DINEN61131-2)
Permissible humidity (storage/transport) 5 % ... 95 % (according to DINEN61131-2)
Air pressure (operation) 70 kPa ... 106 kPa (up to 3000m above sea level)
Air pressure (storage/transport) 58 kPa ... 106 kPa (up to 4500m above mean sea level)
Degree of protection IP20
Protection class III (IEC61140, EN61140, VDE0140-1)
Overvoltage category II
Pollution degree 2
Vibration (operation) 5g (according to EN60068-2-6/IEC60068-2-6)
Shock (operation) 30g (according to EN60068-2-27/IEC60068-2-27)
Continuous shock (operation) 10g (according to EN60068-2-27/IEC60068-2-27)
Connection data
Designation AxiolineF connector
Connection method Push-in connection
Conductor cross section solid / stranded 0.2 mm²  ...  1.5 mm²
Conductor cross section [AWG] 24  ...  16
Stripping length 8 mm
