Phoenix Contact AXC F 3152 User Manual

Ordering data and technical data
107708_en_09 PHOENIX CONTACT 85 / 104
Interface AxiolineF local bus
Connection method Bus base module
Number of interfaces 1
Transmission speed 100 Mbps
Electrical isolation No
Number of supported devices max. 63
Interface Ethernet
Bus system RJ45
Connection method RJ45 jack
Note on the connection method Auto negotiation and autocrossing
Number of interfaces 2
No. of channels 2
Transmission speed 10/100 Mbps (full duplex)
Transmission length max. 100 m
Transmission physics Ethernet in RJ45 twisted pair
Protocols supported HTTP
HTTPS
SFTP
SNTP
IPsec
syslog
OPC UA
System limits
Amount of process data max. 1482 Byte (per station (total input and output data))
max. 1024 Byte (AxiolineF local bus (input))
max. 1024 Byte (AxiolineF local bus (output))
Number of supported devices max. 63 (per station)
Number of local bus devices that can be connected max. 63 (observe current consumption)
Number of IO-Link masters max. 8 (recommended)
NOTE: Electronics may be damaged when overloaded
Observe the logic current consumption of each device when configuring an AxiolineF station. It is specified in
every module-specific data sheet. The current consumption can differ depending on the individual module.
The permissible number of devices that can be connected therefore depends on the specific station structure.
PROFINET
Device function PROFINET controller, PROFINET device
Number of supported devices max. 64 (at PROFINET controller)
Specification Version 2.4
Conformance Class B
Update rate min. 1 ms (4 devices)
min. 16 ms (64 devices)
Number of slots 1
Vendor ID 00B0
hex

Phoenix Contact AXC F 3152 Specifications

General

Brand	Phoenix Contact
Model	AXC F 3152
Category	Controller
Language	English
