AXC F X152
86 / 104
PHOENIX CONTACT 107708_en_09
Device ID 0142
hex
Process data width 512 Byte ()
Supported functions MRP, FSU (), MRP ()
PROFINET
Communications power U
L
feed-in (the supply of the AxiolineF local bus U
Bus
is generated from U
L
)
Supply voltage 24 VDC
Supply voltage range 19.2 VDC ... 30 VDC ()
Current consumption typ. 200 mA (without I/Os and U
L
= 24 V)
max. 442 mA (with 1A at U
Bus
for the I/Os and U
L
= 24 V)
Power consumption typ. 4.8 W (without I/Os)
max. 10.6 W (with 1A at U
Bus
for the I/Os and U
L
= 24 V)
Surge protection electronic
Reverse polarity protection electronic
NOTE: Electronics may be damaged when overloaded
Provide external fuses for the 24 V U
L
area. If you are using an external fuse, the power supply unit must be
able to supply four times the nominal current of the fuse. This ensures that it trips in the event of an error.
AxiolineF local bus supply (U
Bus
)
Supply voltage 5 VDC (via bus base module)
Power supply unit 1 A
Realtime clock
Accuracy realtime clock 1.73 s/day = 20ppm at 25°C
Power reserve 240 h (at 25°C)
Programming Data
Register length (master) 1482 Byte
Programming
Programming tool PLCnext Engineer
Eclipse
Visual Studio
MATLAB
®
Simulink
®
Programming languages supported Instruction list (IL)
Symbolic flowchart (SFC)
Ladder diagram (LD)
Function block diagram (FBD)
Structured text (ST)
C++
C#
Java
Python
Simulink
