Phoenix Contact AXC F 3152 User Manual

AXC F X152
92 / 104
PHOENIX CONTACT 107708_en_09
PROFINET
Device function PROFINET controller, PROFINET device
Number of supported devices max. 128 (at PROFINET controller)
Specification Version 2.4
Conformance Class B
Update rate min. 1 ms (32participants)
min. 2 ms (64 devices)
min. 4 ms (128participants)
Number of slots 1
Vendor ID 00B0
hex
Device ID 0158
hex
Process data width 64 Byte ... 512 Byte
Supported functions FSU ()
Communications power U
L
feed-in (the supply of the AxiolineF local bus U
Bus
is generated from U
L
)
Supply voltage 24 VDC
Supply voltage range 19.2 VDC ... 30 VDC ()
Current consumption typ. 260 mA (without I/Os and U
L
= 24 V)
max. 504 mA (with 1A at U
Bus
for the I/Os and U
L
= 24 V)
Power consumption typ. 6.24 W (without I/Os)
max. 12.1 W (with 1A at U
Bus
for the I/Os and U
L
= 24 V)
Surge protection electronic
Reverse polarity protection electronic
NOTE: Electronics may be damaged when overloaded
Provide external fuses for the 24 V U
L
area. If you are using an external fuse, the power supply unit must be
able to supply four times the nominal current of the fuse. This ensures that it trips in the event of an error.
AxiolineF local bus supply (U
Bus
)
Supply voltage 5 VDC (via bus base module)
Power supply unit 1 A
Realtime clock
Accuracy realtime clock 0.7s/day = 8ppm at 25°C
Power reserve 336 h (at 25°C)
Programming Data
Register length (master) 1482 Byte
