Phoenix Contact AXC F 3152 User Manual

Ordering data and technical data
107708_en_09 PHOENIX CONTACT 93 / 104
Programming
Programming tool PLCnext Engineer
Eclipse
Visual Studio
MATLAB
®
Simulink
®
Programming languages supported Instruction list (IL)
Symbolic flowchart (SFC)
Ladder diagram (LD)
Function block diagram (FBD)
Structured text (ST)
C++
C#
Java
Python
Simulink
IEC 61131 runtime system
Number of data blocks depending on data storage
Number of control tasks 32 (16 per processor core)
Cycle Time 500 µs ()
Program memory 12 Mbyte
Data storage 32 Mbyte
Retentive data storage 1 Mbyte
PLC switch RUN/STOP/RESET switch
Conformance with EMC Directive 2014/30/EU
Immunity test in accordance with EN61000-6-2/IEC61000-6-2
Electrostatic discharge (ESD)
EN61000-4-2/IEC61000-4-2
Criterion B, 6 kV contact discharge, 8 kV air discharge
Electromagnetic fields EN61000-4-3/IEC61000-4-3 Criterion A, Field intensity: 10 V/m
Fast transients (burst) EN61000-4-4/IEC61000-4-4 Criterion B, 2kV
Transient overvoltage (surge)
EN61000-4-5/IEC61000-4-5
Criterion B, DC supply lines: ±0.5 kV/±0.5 kV
(symmetrical/asymmetrical), fieldbus cable shield: ±1 kV
Conducted interference EN61000-4-6/IEC61000-4-6 Criterion A, Test voltage 10 V
Noise emission test according to
EN61000-6-3/IEC61000-6-3
Approvals
For the current approvals, go to: www.phoenixcontact.net/product/1069208
UL, USA / Canada (E238705) cULus
