Description of the Inline Controller
7805_en_02 PHOENIX CONTACT 2-9
FR + FF Flashing
Only applies for ILC 170 ETH 2TX:
There is no SD card in the controller
PWR: Supply voltage
(see also "Remote bus" on page 2-28)
UL Green 24 V supply U
ILC
for generating the voltages U
L
and U
ANA
ON: Supply voltage present
(indication if 24 V supply voltage U
ILC
present)
US Green 24 V supply for segment circuit
ON: Supply voltage present
UM Green 24 V supply for main circuit
ON: Supply voltage present
IL: Diagnostics for INTERBUS
RDY Green INTERBUS master ready to operate/data transmission active
(INTERBUS ready/running)
Flashing: INTERBUS master in READY or ACTIVE state
ON: INTERBUS master in RUN state
FAIL Red Failure
ON: One of the following errors has occurred:
- Bus error in the connected bus (remote bus/local bus)
- Controller error
BSA Yellow Bus segment aborted
ON: One or more bus segments in the connected bus are switched off
PF Yellow Peripheral fault
ON: Peripheral fault of a device in the connected bus (local bus or remote bus)
I/O: Digital inputs and outputs
I1 to I8 Yellow Inputs 1 to 8
ON: Corresponding input is set
E Yellow Error
ON: Short circuit/overload at outputs 1 to 4
Q1 to Q4 Yellow Outputs 1 to 4
ON: Corresponding output is set
Des. Color Meaning
