3.7 Function blocks for Ethernet communication
The function blocks are used to establish Ethernet communication between two
communication partners.
The IP communication blocks listed in the following enable IEC-61131-5-compliant
communication between controllers via Ethernet or communication between controllers
and Ethernet devices via TCP/IP or UDP/IP.
Implement all time and connection monitoring in the application program.
The function blocks are valid for the Inline Controllers listed in the table below in the
specified hardware/firmware versions and enable the specified maximum number of
TCP/IP or UDP/IP communication connections:
Order
designation
Blocks From
hardware
version
From
firmware
version
Ethernet connections
to other
communication
partners (maximum)
ILC 130 ETH
IEC 61131-5
01 3.01 8TCP/IP
UDP/IP
ILC 150 ETH
IEC 61131-5
00
1.00
8TCP/IP 1.00
UDP/IP 2.00
ILC 155 ETH
IEC 61131-5
01 2.04 8TCP/IP
UDP/IP
ILC 170 ETH 2TX
IEC 61131-5
01 3.00 16TCP/IP
UDP/IP
Table 3-2 Overview of function blocks
Function block Short description
IP_CONNECT Establishes a connection between two communication partners
IP_USEND Transmits data to a communication partner
IP_URCV Receives data from a communication partner
The communication blocks are described in the PC WorX online help.
The extensions for the TCP/IP and UDP/IP function blocks are described in the "TCP/UDP
COMMUNICATION" application note.
