UM EN ILC 1XX
3-6
PHOENIX CONTACT 7805_en_02
3.5 Parameterization memory and Internet Explorer
To delete files or store user-specific files on the internal parameterization memory, proceed
as follows:
• Switch to the bus configuration workspace in PC WorX.
• Select the control system, e.g., "ILC 150 ETH", in the "Bus Structure" window.
• Select the "Extended Settings" tab in the "Device Details" window.
• Open Internet Explorer from this window by clicking on the
"Open FTP Folder on Device" button.
Figure 3-5 Extended Settings: Open FTP Folder on Device
The file structure, which is stored in the parameterization memory, is displayed in the
Internet Explorer window.
The FTP function must be activated in Internet Explorer. See "Internet Explorer FTP
function" on page 3-7.
Data may only be copied or deleted in the parameterization memory. Do not edit any files
as Internet Explorer does not store modified data.
For the current state to be displayed, update the display after every action by means of
the "View... Refresh" command.
