Description of the Inline Controller
7805_en_02 PHOENIX CONTACT 2-19
2.12.2 Serial PRG interface (Mini-DIN female connector)
In addition to providing the Ethernet interface, this serial interface enables communication
with the Inline Controller from a PC.
A connecting cable is required for connecting the Inline Controller to a PC with
PC WorX/PC WorX Express via the serial PRG interface.
A connecting cable is required for direct connection of the Inline Controller to a PC with
PC WorX. Connect the connecting cable to the programming interface of the Inline
Controller (designation "PRG") and the serial interface of the PC.
Connection
Figure 2-17 Connecting cable between PC and Inline Controller
This interface can be used to either assign the IP address of the Inline Controller and
access the Inline Controller using the Diag+ diagnostic tool or communicate with special
I/O devices via function blocks (see Section 2.13, "Serial PRG interface").
Ordering data:
Connecting cable for connecting the Inline Controller to a PC (V.24 (RS-232)) for
PC WorX, length 3 m (Order Designation PRG CAB MINI DIN, Order No. 2730611).
AUTOMATIONW
ORX
IL
C
1
50
E
T
H
O
rd
e
r-N
o
.: 2
98
53
3
0
H
W
/F
W
:
00
/1
0
0
M
A
C
A
d
d
r
.:
xx
.x
x
.xx.xx
U
L
U
S
U
M
I1
I3
I2
I4
I6
I5
I8
I7
RESET
E
Q
2
Q
1
Q
3
Q
4
1
1
PRG
F
F
L
N
K
A
C
T
MRESET
RUN/PROG
STOP
F
R
B
S
A
P
FR
D
Y
FA
IL
1
2
4
2
3
5
PC WORX
74060012
