Technical data and ordering data
7805_en_02 PHOENIX CONTACT 5-1
5 Technical data and ordering data
5.1 Technical data
General data
Dimensions 80 mm x 122 mm x 71.5 mm
Weight 285 g, approximately (ILC 130 ETH, ILC 150 ETH, ILC 155 ETH)
295 g, approximately (ILC 170 ETH 2TX)
Connection data for connectors
Connection method Spring-cage terminals
Conductor cross-section 0.2 mm
2
to 1.5 mm
2
(solid or stranded), 24 - 16 AWG
General supply
Use a power supply without fall-back characteristic curve (see "Sizing of the power supply" on page 2-29).
24 V main supply U
M
Connection method Spring-cage terminals
Nominal value 24 V DC
Tolerance -15%/+20% (according to EN 61131-2)
Ripple ±5%
Current consumption at nominal voltage (typical) 6 mA + 7 mA for each input set
Current consumption at nominal voltage (maximum) 8 A
Continuation Through potential routing
Safety equipment
Surge voltage Input protective diodes (can be destroyed by permanent overload)
Pulse loads up to 1500 W are short circuited by the input protective diode.
Polarity reversal Parallel diodes for protection against polarity reversal; in the event of an error
the high current through the diodes causes the preconnected fuse to blow.
NOTE:
Provide external fuses for the 24 V area. The power supply unit must be able to supply four times (400%) the nominal current of the external
fuse, to ensure that the fuse blows safely in the event of an error.
