UM EN ILC 1XX
2-34
PHOENIX CONTACT 7805_en_02
2.16 Digital inputs and outputs
There are eight 24 V DC inputs and four 24 V DC outputs.
Figure 2-24 Assignment of the terminal points of connectors 2 to 4
The descriptions for digital inputs and outputs apply to all the Inline Controllers listed on
the inner cover page of this manual.
A
U
T
O
M
A
T
IO
N
W
O
R
X
ILC 150 ETH
Order-No.: 2985330
HW/FW: 00/100
MAC Addr.: xx.xx.xx.xx
UL
U
S
U
M
I1
I3
I2
I4
I6
I5
I8I7
RESET
E
Q
2
Q
1
Q
3
Q
4
1
PRG
F
F
L
N
K
A
C
T
MRESET
RUN/PROG
STOP
F
R
P
F
R
D
Y
FAIL
7805A011
12
1
2
3
4
1
2
3
4
1.1
1.2
1.3
1.4
2.1
2.2
2.3
2.4
2-3
12
1
2
3
4
1
2
3
4
3.1
3.2
3.3
3.4
4.1
4.2
4.3
4.4
4
Table 2-7 Terminal point assignment
Terminal point Assignment Remark
Connector 2 Output terminal points
1.1 Q1 Output 1
2.1 Q2 Output 2
1.2, 2.2 GND Ground contact for 2 and 3-wire termination
1.3, 2.3 FE Functional earth ground for 3-wire termination
1.4 Q3 Output 3
2.4 Q4 Output 4
Connector 3 Input terminal points
1.1 I1 Input 1
2.1 I2 Input 2
1.2, 2.2 24 V Supply voltage U
M
for 2 and 3-wire termination
1.3, 2.3 GND Ground contact for 3-wire termination
1.4 I3 Input 3
2.4 I4 Input 4
The outputs are supplied with 24 V DC from the segment supply (U
S
).
