UM EN ILC 1XX
2-24
PHOENIX CONTACT 7805_en_02
2.13.3 RS232_RECEIVE
Figure 2-19 RS232_RECEIVE
The RS232_RECEIVE block is used to read the internal receive buffer of the serial interface.
Number of stop bits (stopbits) ILC 13..., ILC 15..., ILC 17...
Code Description
00
hex
1 X
01
hex
1.5 –
02
hex
2 –
Hardware flow control (flowcontrol) ILC 13..., ILC 15..., ILC 17...
Code Description
00
hex
None X
01
hex
Hardware RTS/CTS –
02
hex
XON/XOFF –
Error pattern (error_pattern) ILC 13..., ILC 15..., ILC 17...
Not used –
First delimiter (first_delimiter) ILC 13..., ILC 15..., ILC 17...
Not used –
Second delimiter (second_delimiter) ILC 13..., ILC 15..., ILC 17...
Not used –
XON pattern (XON_pattern) ILC 13..., ILC 15..., ILC 17...
Not used –
XOFF pattern (XOFF_pattern) ILC 13..., ILC 15..., ILC 17...
Not used –
REQUEST
DONE
BUFFER_NOT_EMPTY
STATUS
RS232_RECEIVE
ERROR
BUFFER_FULL
DATA
DATA_COUNT
RECEIVE_BUFFER_COUNT
RS232_RECEIVE_1
7406A021
DATA
